Single Drum Roller – Model: XS83
Discover the XCMG Single Drum Roller – Model: XS83, your ultimate solution for asphalt compaction and construction projects. This reliable and compact roller offers top-tier performance in a small package. Whether you’re looking for a smooth drum roller, dirt packer, or a ride-on vibratory roller, the XS83 delivers outstanding results, making it the perfect choice for your construction needs.
Key Specs
Engine
Cummins QSF3.8
Static Linear Load
221.7
Rated Power
74/99 kW/hp
Op Weight
8000 kg
×
![]()
Product Overview – Single Drum Roller – Model: XS83
Operating Weight
8000 kg
Front Axle Weight
3800 kg
Rear Axle Weight
4200 kg
Static Linear Load (Front /Rear Drum)
221.7 kg/cm
Speed Range
0-5; 0-11 km/h
Theoretical Gradeability
50 %
Minimum Turning Radius
4000/5860 mm
Minimum Ground Clearance
270 mm
Wheel Base
2680 mm
Steering Angle
33 Degrees
Oscillation Angle
10 Degrees
Vibrational Frequency
30/35 hz
Nominal Amplitude
1.8/0.9 mm
Exciting Force
125/85 kN
Engine Type
Cummins QSF3.8
Rated Speed
Rated Speed
Engine Rated Power
74/99 kW/hp
Charge Pressure of Drive System
2.4 MPa
Relief Pressure of Drive System
38 MPa
Relief Pressure of Vibration System
30 MPa
Relief Pressure of Steering System
14 MPa
Not sure which product is right for you? Connect with us today!
