Vibratory Roller – Model: XD140
The XCMG XD140 Double Drum Roller delivers precise, high-frequency asphalt compaction for newly built pavements, thin stabilised layers, and road maintenance work. Its powerful vibration system, strong excitation force, and independent front and rear drum control ensure smooth, consistent results on every pass.
Compact, highly manoeuvrable, and designed for operator comfort, the XD140 offers excellent visibility, flexibility, and efficiency — making it an ideal choice for municipal roadworks, highway maintenance, and precision asphalt finishing.
Key Specs
Engine
KUBOTA V2403
Static Linear Load
152/160N/cm
Speed
0～12 km
Op Weight
4300kg
×
![]()
Product Overview – Vibratory Roller – Model: XD140
Operating Weight
4300 kg
Front Axle Weight
2100 kg
Rear Axle Weight
2200 kg
Static Linear Load
152/160 N/cm
Operating Speed
0~12 km/h
Theoretical Gradeability
30%
Minimum Turning Radius(Inside/Outside)
Inside: 2700 mm Outside: 4100 mm
Minimum Ground Clearance
350 mm
Wheelbase
1950 mm
Steering Angle
±32°
Oscillation Angle
±8°
Braking Distance
3.4 m
Vibrational Frequency
53/60Hz
Nominal Amplitude
0.5 mm
Centrifugal Force (High/Low)
252/181 kN
Drum Diameter
920 mm
Working Width
1380 mm
Engine Model
KUBOTA V2403
Engine Type
Inline four-cylinder water-cooled
Rated Power
33.6 kW
Rated Speed
2400 r/min
