Vibratory Roller – Model: XD140VT
The XCMG XD140VT Combination Roller delivers advanced versatility with its vibratory steel drum and static rubber tyres, enabling both deep compaction and smooth surface finishing in a single, efficient machine.
Designed for larger work areas and more demanding tasks, the XD140VT excels in road construction, pavement repair, infrastructure upgrades, and redevelopment projects. Its dual-mode compaction system ensures consistent density, exceptional surface quality, and high productivity across a wide range of materials.
Key Specs
Engine
KUBOTA V2403
Static Linear Load
152 N/cm
Speed
0～12 km/h
Op Weight
4000kg
×
![]()
Product Overview – Vibratory Roller – Model: XD140VT
Operating Weight
4000 kg
Front Axle Weight
2100 kg
Rear Axle Weight
1900 kg
Static Linear Load (Front/Rear)
152 N/cm
Operating Speed
0～12 km/h
Theoretical Gradeability
30%
Minimum Turning Radius(Inside/Outside)
Inside: 2700 mm, Outside: 4100 mm
Minimum Ground Clearance
350 mm
Wheelbase
1980 mm
Steering Angle
±32°
Oscillation Angle
±8°
Excitation Force (High/Low Frequency)
36/41 kN
Braking Distance
3.40 m
Vibrational Frequency
53/60 Hz
Nominal Amplitude
0.5 mm
Drum Diameter
920 mm
Drum Width
1380 mm
Engine Model
KUBOTA V2403
Engine Type
Inline four-cylinder water-cooled
Rated Power
33.6 kW
Rated Speed
2400 r/min
